Hydraulic Eagle Beak Scrap Shear is a high-performance attachment designed for excavators, widely used in scrap metal processing, steel structure demolition and car dismantling.
With its unique eagle-beak jaw design, this shear provides strong biting force and excellent cutting efficiency for various materials such as steel beams, steel plates, steel pipes and scrap metal.
The shear is driven by a high-power hydraulic cylinder with a reinforced linkage structure, ensuring powerful cutting force, stable performance and long service life.
It is an ideal tool for demolition projects, scrap recycling plants and steel structure dismantling works.
Main Features:
High-strength steel structure, durable and wear-resistant
Powerful hydraulic cylinder with strong cutting force
Eagle-beak jaw design for easy gripping and fast cutting
Reinforced pivot and blade structure for long service life
Easy installation, suitable for various excavator brands
Low maintenance cost and high working efficiency
Applications:
Scrap metal cutting
Steel structure demolition
Car and equipment dismantling
Factory dismantling projects
Recycling plants
| Model: | ESS-18T | ESS-30T | ESS-40T | ESS-55T |
| Excavator | 13–18T | 22–30T | 30–40T | 45–55T |
| Weight | 1350 kg | 2670 kg | 3300 kg | 5300 kg |
| Opening Size | 485 mm | 550 ±10 mm | 650 mm | 770 mm |
| Overall Size (L×W×H) | 2510×700×942 mm | 2844×750×1019 mm | 3300×880×1245 mm | 3910×922×1550 mm |
| Cutting Depth | 438 mm | 525 mm | 630 mm | 714 mm |
| Rear Cutting Force | 105 ton | 295 ton | 350 ton | 230 ton |
| Front Cutting Force | 60 ton | 122 ton | 175 ton | 110 ton |
| Working Pressure | 25–30 MPa | 30–32 MPa | 30–32 MPa | 32–35 MPa |
| Oil Flow | 120–160 L/min | 230–280 L/min | 260–300 L/min | 300–320 L/min |
| Cycle Time | 8–12 s | 8–12 s | 8–12 s | 8–12 s |
| Steel Rod | Φ50 mm | Φ55 mm | Φ80 mm | Φ90 mm |
| U-Beam | 140×8 mm | 400x100x18 mm | 500x100x18 mm | 360×98 mm |
| H-Beam | 250×116 mm | 350x300x10 mm | 500x300x14 mm | 560×170 mm |
| I-Beam | 250×116 mm | 280x122x10 mm | 360x140x14 mm | 560×170 mm |
| Angle Steel | 200x200x15 mm | 200x200x15 mm | 200x200x25 mm | 200x200x30 mm |
| Steel Plate | 12 mm | Width 250 x T30 mm | Width 250 x T30 mm | 30 mm |
| Steel Pipe | Φ159×6 mm | Φ220×8 mm | Φ330×10 mm | Φ402×15 mm |
